FMM |Motorcycle Diagnostic Scan Tool

THE INDUSTRY LEADER IN AUTO DIAGNOSTICS

FCAR FMM |Motorcycle Diagnostic Scan Tool

Introduction

The FCAR FMM is the latest integrated diagnostic tool developed by FCAR to detect malfunctions in the motorcycle electronic control system, currently available to diagnose more than 90% models of the motorcycle brands, such as YAMAHA, SUZUKI, HONDA, KAWASAKI, etc. The FMM software will be updated continuously for future needs in which sense one machine would suffice. With friendly UI design and ultra-practical maintenance to help customers handle problems rather quickly. It is easy to operate and up to the need s o f all- size d maintenance enterprise training institutions, manufacturers and so on.

Feature



  • VCI box connect with motorcycle bikes, operate via smart phone
  • Makes included: Yamaha, Suzuki, Honda, Kawasaki, Kymco, and Euro 4
  • Comprehensive diagnostics with codes, live data graphing, etc
  • One-click update and feedback
  • Wi-Fi and mobile Internet
  • access capable Multi-language support

Product specification

The processor

Cortex®-M3

Frequency

72MHZ

Bluetooth

V2.1+EDR, BT3.0, BT4.1

RAM

128KB





Bluetooth module

4.4

Product size

115*70*24mm

Weight

90g

Operating temperature

0℃-50℃

Storage temerpature

-20℃-70℃

Input voltage

12/24V





F7S-W For Passenger & Light Commercial Vehicles

Fcar

F7S-W ( 12V Passenger &Light Commercial Vehicles )

F7S-W, Android based brand new all-in-one diagnostic solution with WIFI and Bluetooth, covering over 80 manufacturers from America, Asia, Europe, supporting powerful basic, special diagnostic and maintenance functions, diagram

*Based on Android system, equipped with Wi-Fi and Bluetooth.
*Fast booth-up and multitasking.
*Support powertrain, body, chassis and information systems etc.
*Support quick test for most vehicles.
*Support automatic detection system.
*Support one key update/recognition/complaint.
*Records and playback test report.
*Support live data in text, graph and gauge format.
*Support freeze frame data.
*Support multi language.
*Instant support available from FCAR technical team via TeamViewer.
*With diagram wiring, technical information, diagnostic solutions and maintenance services.
*Support multimedia entertainment, instant messaging and data sharing.
*Extensive vehicle coverage: Over more than 80 Asian, American and European passenger cars, LCV, SUV, Van.
*Compatible with latest 2015/2016/ model and some even can support 2017.
*Compatible with both EOBD and OBDII protocol
*Support key coding/long coding for some vehicles.
*Powerful basic and special functions for all vehicles.


Specification

Tablet CPU Freescale semiconductor (quad-core ),I.MX6Q,1.2GHz,
Operation System Android 4.3
Screen Size 10.1‘   16:10  ,1280*800   IPS
Storage Capacity RAM:2GB ;ROM  :32GB
WIFI WiFi 802.11(a/b/g/n)   Frequency 2.4G+5.8G dual band WiFi,
Bluetooth BT4.0 (BLE) class1 transmission distance10m
Battery Lithium-ion polymer battery,3.7V/10000mAh
Operate Temperature ‘-10 °C to 50 °C / 14 °F to 122 °F
Store Temperature ’-30 °C to 70 °C / -4°F to 140 °F

Functions:

  Read / Clear DTC  Display ECU Information
  Read / Write QR Code  Read / Save Data Stream
  Show Live Data  Display Freeze Frame Data
  Key Programming  Compression Test
  Service Reset  Bi-directional Injector Testing
  Cylinder Test  Component Test
  Actuation Test  Adaption
  On-line Study  Maintenance Help

Special Functions:

  Service Reset  Throttle Reset
  Odometer Calibration  EPB Reset
  Key Programming  EPS Reset
  ECU Reset  SRS Reset
  ABS Exhaust  TPMS
  DPF  CKP Learning
  Headlight Adaption  Suspension System
  Windows



F6 PLUS (12V Passenger &Light Commercial Vehicles)

F6 PLUS - 12V Passenger And Light Commercial Vehicles

F6 PLUS, Android based brand new all-in-one diagnostic solution with WIFI and Bluetooth, featuring waterproof, anti-scratch, anti-drop and anti-oil, covering over 80 manufacturers from America, Asia, Europe, supporting powerful basic, special diagnostic and maintenance functions, remote support and online update.

Features

  • Based on Android system, equipped with WiFi and Bluetooth.
  • IP67 rating allowing F6 Plus against dust, water, shock and bumps.
  • Fast booth-up and multitasking.
  • Support power-train, body, chassis and information systems etc.
  • Support quick test for most vehicles.
  • Support automatic detection system.
  • Support one key update/recognition/complaint.
  • Records and playback test report.
  • Support live data in text, graph and gauge format.
  • Support freeze frame data.
  • Support multi language.
  • Instant support available from FCAR technical team via Teamviewer.
  • With diagram wiring, technical information, diagnostic solutions and maintenance services.
  • Support multimedia entertainment, instant messaging and data sharing.
  • Extensive vehicle coverage: Over more than 80 Asian, American and European passenger cars, LCV, SUV, Van.
  • Compatible with latest 2015/2016/ model and some even can support 2017.
  • Compatible with both EOBD and OBDII protocol
  • Support key coding/long coding for some vehicles.
  • Powerful basic and special functions for all vehicles.

Specifications

PatternIP67 rating
Dimension228mm*147mm*16.5mm
Display8-inch, 16:10, 800*1280IPS screen
Touch Screen5-dot capacities screen,G+G,hardness 7H+,scratch-resistant,TP thickness: 1.1mm, COF, support hand writing
BluetoothSupport for Bluetooth 2.0 and 4.0
WiFiWiFi 802.11(a/b/g/n) Frequency: 2.4G+5.8G dual band WiFi
Operation SystemAndroid 4.4
CAN-BUSHigh/low/single CAN supported
ProtocolCAN K-Line/L-Line commercial maker

F5-W / F5-G Diagnostic Scanner

F5-W / F5-G Diagnostic Scanner FCAR

F5-G,the most advanced model in FCAR and it is designed to deliver the most comprehensive diagnosis functions to the users all over the world. With widest coverage, all passenger car and LCV, heavy duty trucks, diesel engines, construction machinery.

WHAT ARE THE UNIQUE FEATURES OF F5-G?
  • High compatibility enables F5-G as an all-in-one tool to diagnose passenger & light commercial vehicles and heavy duty trucks.
  • Enormous database includes more than 200 vehicle models and technical materials to provide better and faster troubleshooting diagnosis solutions to meet various customer‘s needs.
  • Specially designed to test engines, transmissions, ABS and many other systems made by different manufacturers.
  • Powerful capacity to support all kinds of electronic control system diagnosis of diesel engines from Europe, America and Asia, and support a variety of protocols like standard high&low Can-Bus, J1939 and Other communication protocols.
DON’T FORGET FCAR PERFECT SERVICE!
  • Localized vehicles
    India: Mahindra, Maruti, Tata.
  • Malaysia: Perodua, Proton, Inokom.
  • Iran: Iran Peugeot, Saipa.
  • South Africa: Opel.
  • Australia: Holden.
  • Multi-languages make it easy understanding and operation.
  • Perfect experience of one-to-one after-sale service to solve any question.

F3S-W LIGHT DUTY DIAGNOSTIC SCANNER

F3 S-W - Light Duty Diagnostic Scanner

An OEM automotive diagnostic scanner F3S-W provides advanced technology and good performance for 12 voltage diesel and gasoline over European, American and Asian vehicle makes. F3S-W applies to large ,medium, small maintenance enterprises

Features

F3S-W is the newest version of multi-functional intelligent automotive scanner which is specialized to design for the diagnosis of Light Duty Petrol, Diesel and Gas driven 12V engine electronic control systems by FCAR Company. Built-in high and low speed CAN-BUS, one OBD Connector supports almost all OBD-II protocols.

Functions

Readout DTC, Readout Engine Model, Readout Computer Edition Information, Readout QR code, Readout System parameter number, Readout Data Stream, Clear DTC, Component test, Compression Test, Maintenance Help, Study on line and so on.

Specifications

ProcessorARM9+ARM7 Dual Processors
Memory 16G SD Card
Display8″ TFT Color Touch Display
Printer58mm Built-in Thermal Printer
Input Voltage8.0-30.0V
Operating Temperature0 to 50°C (32 to 122 °F)
Operating Temperature“-10 to 60°C (14 to 140 °F)

F7S-G (24V Heavy Duty Vehicles & 12V Passenger & Light Commercial Vehicles )

Fcar

F7S-G (12V Passenger & Light Commercial Vehicles & 24V Heavy Duty Vehicles)

F7S-G,FCAR diagnostic tablet platform, based on Android system,built-in WiFi and Bluetooth, supporting powerful diagnostic functions and bidirectional special funciton, diagram wiring, remote support and online update, provides customers with all-in-one d

FUNCTIONS AND FEATURES

1. Instant remote technical support, via Teamviewer, Skype, Whatsapp, etc.
2. One click feedback
3. One click update
4. Online technical information and wiring diagram
5. All-in-one diagnostic solution system for automotive aftermarket workshop
6. Multi-languages make it easy understanding and operation.
7. Localized vehicles, including Indian, Malaysian, and Australian.
8.12 months warranty and 2 years free software update.
9. Enormous database includes more than 200 vehicle models and technical materials to provide better and faster troubleshooting diagnosis solutions to meet various customers’ needs.
10. as an all-in-one automotive diagnostic system to diagnose passenger & light commercial vehicles and heavy duty trucks.
11. VIN automatic detection for passenger cars.

Special function of F7S-G:

ABS EXHAUST, BATTERY MATCH, DPF, ECU PROGRAM, ECU RESET, EPB, LAMP ADAPTION, SAS, SERVICE RESET, SMARKEY PROGRAM, SRSRESET, SUSPENSION, THROTTLE RESET, TPMS, WINDOWS, ODOMETER



Specification

Tablet CPUFreescale semiconductor (quad-core ),I.MX6Q,1.2GHz,
Operation SystemAndroid 4.3
Screen Size10.1‘   16:10  ,1280*800   IPS
Storage CapacityRAM:2GB ;ROM  :32GB
WIFIWiFi 802.11(a/b/g/n)   Frequency 2.4G+5.8G dual band WiFi,
BluetoothBT4.0 (BLE) class1 transmission distance10m
BatteryLithium-ion polymer battery,3.7V/10000mAh
Operate Temperature‘-10 °C to 50 °C / 14 °F to 122 °F
Store Temperature’-30 °C to 70 °C / -4°F to 140 °F

Motorcycle Scan Tool

Introduction FMM Scanner

Motorcycle Scan Tool

The FCAR FMM is the latest integrated diagnostic tool developed by FCAR

detect malfunctions in the motorcycle electronic control system, currently

available to diagnose more than 90% models of the motorcycle brands, such

as YAMAHA, SUZUKI, HONDA, KAWASAKI, etc. The FMM software will be

updated continuously for future needs in which sense one machine would

suffice. With friendly UI design and ultra-practical maintenance to help

customers handle problems rather quickly. It is easy to operate and up to the

needs of all-sized maintenance enterprises, training institutions,

manufacturers and so on

Feature

VCI box connect with motorcycle , operate via smart phone

• Makes included: Yamaha, Suzuki, Honda, Kawasaki, Kymco, and Euro 4

• Comprehensive diagnostics with codes, live data graphing, etc

• One-click update and feedback

• Wi-Fi and mobile Internet access capable

• Multi-language support



Product Specification

The processorCortex@-M3
Frequency72MHZ
BluetoothV2.1+EDR, BT3.O, BT4.1
RAM128KB
Bluetooth module4.4
Product size115*70*24mm
Weight90g
Operating temperature0°c-50C°
Storage temperature-20°C – 70°C
Input voltage12/24V


F7S-M Professional Diagnostic

Professional Motorcycle Scan Tool

FCAR F7S-M is a professional Diagnostic tablet Platform for Motorcycle

FCAR F7S-M is a professional diagnostic tablet platform for motorcycle, which supports many brands like BMW, Euro4, Honda, Kawa, KTM, Kymco, Suzuki,Yamada etc. F7S-M provides various functions including Read Fault Code,Erase Fault Code, Read Data Stream, Read ECU Information, Special Function and so on. With powerful hardware and advanced software, F7S-M is one of the best motorcycle scan tools in the market for workshops, training institutions, manufacturers, mechanics and even for personal use.

Motorcycle Diagnostic System Feature

• Support Bluetooth, WiFi and USB data transportation;

•10.1-inch IPS High-Brightness Display with 10-point touch;

•Support all-size standard USB 2.0 connector;

•Comprehensive diagnostics with codes, live data graphing etc;

•Support BMW, Euro4, Honda, Kawa, KTM, Kymco, Suzuki, Yamada, etc.AVE OPTIONS

Specification

Display10.1-inch IPS LCD, 16:10, 10-point touch
BluetoothBluetooth 4.0
Wifi802. 11(a/b/g/n) 2.4 G + 5.8 G Frequency, dual band
Video OutputHDMI
SYSTEMANTROID
BATTERY3.7V/10000mAh Lithium-ion polymer
Diamension320*210*30mm

C8-M |Scan Tool Diagnostic Platform for Motorcycle

THE INDUSTRY LEADER IN AUTO DIAGNOSTICS

C8-M | Most Trustworthy Scan Tool Diagnostic Platform for Motorcycle

FCAR C8-M is the latest diagnostic platform developed for motorcycle. With

various connecting cables, C8-M supports diagnosis for Yamaha, Suzuki,

Honda, Kawasaki, Kymco, and Euro 4. The friendly UI and powerful system

provide many functions like Read/Clear Fault Code, Actuation Test, CO

Adjustment, Front Brake Bleeding, ISC RPM Control. The diagnostic tablet

comes with much smaller size and more powerful specifications, delivering

better user experience and smoother daily operation. C8-M is one of the most

advanced and trustworthy motorcycle scan tools.

Features

-Support online update via WiFi

-HDMI, Type-C, USB port, TF card slot

-Bluetooth-enabled professional diagnostic platform for motorcycle

-Comprehensive diagnostics with codes, live data graphing, etc

-Support Yamaha, Suzuki, Honda, Kawasaki, Kymco, and Euro 4

-Remote control makes it available to get quick support from FCAR

SPECIFICATION

Screen8-inch 1280*800 IPS Panel
ChipsetCortex A17 RK3288 Quad-Core
ConnectionBluetooth 4.0; WiFi 2.0
PortUSB,HDMI,TF SLOT
Dimension232*159*27mm

Functions

-Reboot ECU

-Actuation Test

-CO Adjustment

-ISC RPM Control

-Read Data Stream

-Rear Brake Bleeding

-Front Brake Bleeding

-Read ECU Information

-Read/Clear Fault Code

-ISC Air Volume Control
